PANASONIC AW-HS50 (AW-HS50E) MultiFormat / Multiviewer SWITCHER HD/SD-SDI - 5 Inputs -
AW-HS50Brand: PANASONIC
Pret Lei (pret fara TVA) : 15,312 Lei
Nu exista manuale disponibile pentru acest produs.
PANASONIC AW-HS50 (AW-HS50E) MultiFormat / Multiviewer SWITCHER HD/SD-SDI - 5 Inputs -
Panasonic AW-HS50 este un mixer video (switcher) multiformat, extrem de compact dar foarte puternic, cu calitate Broadcast, dedicat productiilor mobile TV / Evenimente / Wedding dar si pentru studiourile TV sau case de productie cu buget limitat dar care nu vor sa faca nici un rabat de calitate. Mixerul video AW-HS50 este prevazut cu 5 intrari (Inputs) dintre care 4 intrari HD/SD-SDI si o intrare HD DVI-D (toate cu sincronizator de cadre 10 bit pe fiecare intrare) si are 2 iesiri (Outputs) HD/SD-SDI si o iesire DVI-D. AW-HS50 are integrate: un Multiviewer - ce permite utilizatorilor sa vizualizeze 4, 9 sau 10 imagini pe un singur display conectat prin iesirea high resolution - , functia picture in picture (PinP), posibilitatea de a efectua tranzitiile auto sau manual, un chroma keyer, un downstream keyer (DSK), un AUX BUX - care conectat la noul model de controller AW-RP50 permite selectarea oricarei camere robotizate PTZ in caz ca este folosit intr-o aplicatie de acest gen - si o interfata Ethernet pentru conectarea la retea. Panasonic AW-HS50 suporta cele mai raspandite formate video de productie: in HD (1080/59.94i, 1080/50i, 1080/23.98PsF, 1080/24PsF, 720/59.94p, 720/50p), in SD (480/59.94i, 576/50i). Dimensiunile liliputane ii permit instalarea untr-un flight case (studio mobil) pe doar o jumatate de rack ! , iar daca se doreste folosit ca atare (fara nici un case) devine visul oricarui operator care are de transportat un mixer cu dimensiunea a 4 pachete de tigari king size si care cintareste doar 1.4 kg. Declarat drept Cel Mai Performant Mixer Video HD pentru Broadcast din Lume la aceste dimensiuni ! Comentariile pe forumuri au si inceput: churchmedia.net. Detalii pe site-ul producatorului, panasonic.net. Reviews utilizatori din lumea intreaga pe bhphotovideo.com. Ideas for Life. Panasonic. Made in Japan.
cod: AW-HS50General
- HD: 1080/59.94i, 1080/50i, 1080/23.98PsF, 1080/24PsF,720/59.94p, 720/50p
- Up-converter: SDI-IN3, IN4
- 1, tranzitie BUS
- Materiale selectabile: SDI-IN1 to 4, DVI-IN, CBAR, CBGD, BLACK, FMEM1, FMEM2, PGM, PVW, KOUT, CLN, MV
- Frame Synchronizer: SDI-IN1 to 4, DVI-IN (DVI-IN is always-on)
- Freeze: SDI-IN1 to 4, DVI-IN
- Dot by Dot: SDI-IN1 to 4
- Video Processing: SDI-IN1 to 4
- MultiViewer: Single Screen Display Labels, Tally indication, Split-screen (the screen may be split into 4, 5a/5b, 6a/6b, 9 and 10a/10b sections) MV frames, Labels, Tally indications, camera setting information, and Audio Level Meters are not shown on SDI-OUT1
- Mix
- OSD: Single Screen Display, SDI-OUT2,DVI-OUT (unshown on SDI-OUT1)
- Audio Level Meter: SDI embedded audio (group1/ 1 ch, 2 ch)
- DC12 V/2 A ±10 % (adapter AC inclus)
- De la 0°C la +40°C
- Intre 10% si 90%
- 210 mm x 67 mm x 177 mm
- 1, tranzitie Mix, tranzitie BUS
- Linear key, Luminance key, Chroma key
- SD: 480/59.94i, 576/50i
- DVI-D: 1 (DVI-OUT), XGA (1024 x 768), WXGA (1280 x 768), SXGA (1280 x 1024), SXGA+ (1680 x 1050), UXGA (1600 x 1200), WUXGA (1920 x 1200)
- Y:Cb:Cr: 4:2:2 10 bit (8 bit for FMEM)
- RGB: 4:4:4 8 bit
- SDI: 4 (SDI-IN1 to 4)
- DVI-D: 1 (DVI-IN), XGA (1024 x 768), WXGA (1280 x 768), SXGA (1280 x 1024), WSXGA+ (1680 x 1050), UXGA (1600 x 1200), WUXGA (1920 x 1200)
- Frecventa Verticala: 60 Hz 1080/50p, 1080/59.94p
- SDI: 2 (SDI-OUT1 to 2 each, 2 output distribution for SDI-OUT1)
- Frecventa Verticala: 60 Hz 1080/50p, 1080/59.94p
- 1
- 13
- 10BASE-T/100BASE-TX (for IP control/RJ45 x 1)
- Intrare GPI: 5 canale
- Iesire GPI: 7 canale
- 1 D-sub 15 pin (female)
- Cut, Mix, Wipe (incluzand DVE)
- 1.4 kg
mixer video ( switcher ) Panasonic AW-HS50 ; cablu alimentare , cablu curent ; 2 ani garantie Panasonic .
